Feature
(1)In accordance with the standard of API 8A .
(2)Especially built-in hollow with good hydro bump-absorbing capability .
(3)The major hook has double safety devices .
(4)The main components of the hook adopt high tense alloy and get through non-destructive testing .
|
Model No. |
DG315 |
DG450 |
DG675 |
|
Max. hook load (KN) |
3150 |
4500 |
6750 |
|
Spring travel mm(in) |
200(8) |
200(8) |
220(8 5/8) |
|
Major-hook opening mm(in) |
220(8 5/8) |
220(8 5/8) |
234(9 1/4) |
|
Overall Dim mm (length*height*width) |
2960*890*830 |
2960*890*880 |
3705*1210*930 |
|
Weight KG |
3410 |
3500 |
7065 |
