Light Duty workover rigs

Description

The
whole unit structure is compact. It uses hydraulic + mechanical
transmission with high synthetically efficiency. The workover rig adopts
Class Ⅱ
carrier having a few kinds to meet user’s requirements. The mast is
face open single or double telescoped sections, hydraulically or
mechanically raised and telescoped.

Parameter

Model	XJ150	XJ250	XJ350
Max. hook load KN	490	700	900
Rated hook load KN	300	400	600
Service depth m (27/8”tubing)	2600	3200	4000
Workover depth m (27/8”DP)	—	2000	3200
Engine power KW(HP	175KW 233HP	208KW 277HP	269KW 359HP
Active rope number	6	6	6
Mast height m	16、18	18、21	29、31.3
Driving type	6X6	6X6	8X8(single) 10X8(double)
Rope OD	Ø22	Ø22	Ø26
