MWM Gas Power Plant

Description

1.General Introduction
MWM is a market leader when it comes to providing extremely efficient, precise-fitting and environmentally friendly energy solutions.MWM is a reliable partner which can add demonstrable, long-lasting value to global, decentralized energy generation applications.
MWM gas genset is a worldwide famous brand with application for different areas such as landfill gas, coal mine gas, sewage gas, biogas, natural gas etc. with electrical power range from 400kW to 4300kW per unit, and globally and technologically leading position.

2.Features
 Gas engine TCG 2016 –
          Output range from 400 to 800 kW
Consumes up to 15% Less Gas than Comparable Gensets
Long Service Intervals
Very Low Lubricant Consumption
Low Installation Costs
TEM Control Enables Use of Diverse Gas Types

Gas engine TCG 2020
         Output range from 1,200 to 2,000 kW
High Profitability & Higher Efficiency
Optimized for Isolated Operation and Non-ISO Conditions
Lower Pollutant Emissions
Long Maintenance Intervals
Maximum Output at Low Costs

 Gas engine TCG 2032 –
          Output range from 3,000 to 4,300 kW
High Efficiency and Low Lubricant Consumption
Soot-Free Combustion Increases Plant Profitability
New Turbocharger Technology Increases Genset Availability
Compact Engine Design for Easy Transport and Installation
Up to 20 Percent Lower Service Costs

3.Benefits
More Profit
Longer Runtimes
Greater reliability
Optimum Efficiency
Full Turbo Power

Parameter

Engine type

Electrical  Power

(Kw)

Bore/stroke(mm)

Displacement(L)

Thermal  Output

(Kw)

Electrical  Efficiency nel (%)

Total  Efficiency ntot (%)

Dimension

(L/H)

TCG2016 V08 C

400

132/160

17.5

427

45.0

87.2

3090X1480X2280

TCG2016 V12 C

600

132/160

26.3

654

45.7

87.7

3680X1480X2280

TCG2016 V16 C

800

132/160

35

855

45.2

87.5

4060X1480X 2280

TCG2020V12K1

1000

170/195

53.1

1177

40.0

87.0

4636X1870X2490

TCG2020V12K

1125

170/195

53.1

1272

41.0

87.4

5450X1870X2490

TCG2020V12

1200

170/195

53.1

1197

43.7

87.2

5450X1870X2490

TCG2020V16K

1500

170/195

70.8

1691

41.0

87.2

6170X1870X2490

TCG2020V16

1560

170/195

70.8

1586

43.3

87.3

6170X1870X2490

TCG2020V20

2000

170/195

88.5

1990

43.7

87.0

7820X2140X2620

TCG2032V12

3333kw

260/320

203.9

3295

43.5

86.5

8100X2700X3800

TCG2032V16

4300kw

260/320

271.8

4274

43.5

86.7

9300X2700X3800

* NOx < 500 mg/mn3      **Dry exhaust manifolds     *** Methane number≥70

1> NOx emissions: NOx<0.5g NO2/mn3dry exhaust gas at 5% O2
2> According to ISO 3046/1 at U=0.4 KV, cosphi=1 for 50 Hz, at U= 0.48 KV, cosphi=1 for 60 Hz.
3> Exhaust gas cooled to 120 ℃ with natural gas. Specifications for special gases and two-gas operation on request. The figures in these data sheets are for information purposes only and are not binding. The information given in the offer is decisive.
