Screw Compressor Series

Description

Product Features：
1.Design concept of safety first and high-efficiency gas processing;
2.Integral loading control system 15-100%;
3.High-efficiency oil separating system;
4.Minimized noise (sync rotating and oil filling);
5.Pipeline noise inhabitation design;
6.Direct driver design;
7.Single or double shaft sealing system;
8.Single and double loop control;
9.Compressor chamber oil filling;
10.Single cylinder type series and parallel connection, two stages system for option.

Parameter

Item Type			KCS430-01	KCS430-01	KCS300-01
Frequency		Hz	50
Volume flow		Nm3/h	20720	8500	1600
Volume flow		MSCFD	30.5	12.5	2.4
Suction condition	P	MpaA	0.093	0.104	0.102
	P	PsiA	13.5	15.1	14.8
	T	℃	35	20	38
	T	℉	95	68	100.4
Discharge temperature		MpaA	0.38	0.65	1.10
Discharge temperature		PsiA	55.1	94.25	159.5
Driver power		KW	2000	1120	315
Gas composition			Syn. gas	Syn. gas	Syn. gas
Cooling style			Water	Air	Air
Size(LWH)		mm	5360X3000X2200	5250X2400X2440	4400X1800X1635
Weight		Kg	30100	38900	14300

Item Type			KCS40M-02	KCS12M-02	KCS41M-02
Frequency		Hz	50
Volume flow		Nm3/h	4000	260	9000
Volume flow		MSCFD	5.9	0.4	13.2
Suction condition	P	MpaA	0.1	0.1	0.15
	P	PsiA	14.5	14.5	21.8
	T	℃	-25	35	0
	T	℉	-13	95	32
Discharge temperature		MpaA	1.50	1.40	1.70
Discharge temperature		PsiA	217.5	203	246.5
Driver power		KW	710	55	1400
Gas composition			NH3	CH4	C3H8
Cooling style			Water	Air	Water
Size(LWH)		mm	9000X2300X3500	3500X1900X1800	10500X2600X3800
Weight		Kg	15000	3500	200000
